Features
- Cellulosic-coated electrode
- Designed for root beads & hot passes in a wide range of pipe steels
- Suitable for vertical up & down welding
- For site welding of pipe and pipelines in all positions using conventional stove pipe techniques
- Smooth arc characteristics make it ideal for use with misaligned joints and poor fit up
- Ideal for high speed completion of vertical-down root beads
Specifications
Weight | 20 kg |
Data Sheet | https://www.rapidwelding.com/files/2708323044.pdf |
Diameter | 3.2mm |
Length | 350mm |
Alloy Type | CMn |
Coating Type | Cellulosic |
Polarity | AC, DC+- |
Minimum AC OCV | 65 |
Classifications | EN 499: E 38 2 C 11, SFA/AWS A5.1: E6011, BS 639 (1986): E 43 32 C (14), EN ISO 2560-A: E 38 2 C 11 |
Welding Positions | 1, 2, 3, 4, 5, 6, 7, 8, 9 |
Welding Current (A) | Min 60, Max 125 |
Weight (W) | 2.7 kg / 100 electrodes |
Efficiency (η) | 68.6 g weld metal x 100 / g core wire |
Effective Value (N) | 0.69 kg weld metal / kg electrodes |
Changes (B) | 67 number of electrodes / kg weld metal |
Deposit Rate at 90% of max current (H) | 1.0 kg weld metal / hour arc time |
Fusion Time at 90% of max current (T) | 57 s / electrode |
Arc Voltage (U) | 25 V |
