Summary
Documentation
3 year warranty & 1-year warranty on torch
Package comes complete with :
Handy Torch 60A Plasma Torch
Work Cable and Clamp
Wrench for Air Filter
Nitto Air Line Connector
Shoulder Strap
Operating Manual
Handyplasma 45i spec.
Mild Steel Clean Cut 16 mm
Mild Steel Severance 24 mm
Stainless Clean Cut 12 mm
Aluminium Clean Cut 10 mm
Piercing Capacity 10 mm
Input Power 240V, 1 ph, PFC, 15A
Duty Cycle 45A @ 35%
Input Air Required 7.3 Bar, 110 l/min
Generator Required 9 kVA
Dimensions L x W x H 415 x 176 x 324 mm
Weight 11.8 kg
Parts.
HandyPlasma 60A Plasma Torch 0559337000
Plasma Cutting Tip 35A (5 pcs) 0559337001
Plasma Cutting Tip 45A (5 pcs) 0559337002
Electrode (5 pcs) 0559337003
Plasma Standoff Guide 0559337004
Plasma Shield Cup 0559337005
Plasma O-Ring 0559337006
Plasma Torch Gas Diffuser 0559337007
Inline Air Filter 0559337039
Plasma Filter Cartridge 0559337040
Circle Cutting Guide 0559337041
ESAB Warranty
This product is covered by the ESAB Warranty.
ESAB products are backed by one of the most comprehensive warranty programs covering both parts and labour in the industry. In the rare instance of a product defect, the product warranty covers the cost of replacing materials that have become defective due to faulty design and / or workmanship plus the time reasonably required to replace the defective part.
For more information, please see the manufacturer's warranty terms and conditions, or to make a claim, contact us directly.
