Features
- XXL screen for a wide field of view
- High sensitivity with 4 sensors for reliable arc detection
- Suitable for TIG welding from 2A
- External shade adjustment and grinding mode for convenience
- Internal settings for sensitivity and delay
- Active filter with shades 5-9/9-13
- Special low intensity range 5-9
- TRUE COLOR technology for accurate color reproduction
- Excellent optical class 1/1/1/1 (EN379)
- Fast darkening speed: 0.08 ms
Specifications
EAN Code | 3154020068698 |
Weight | 540g |
UV/IR Protection Level | 15 |
Classification | 1/1/1/1 |
Light Tint | 3 |
Dark Tint | 5-9 / 9-13 |
Reaction Time | 0.08 ms |
Clear Reversion Time | 0.15 to 0.8 sec |
Field of View | 100 x 93 mm |
Energy | Solar + batteries (CR2032*2) |
Settings | Sensitivity, delay, tint, grinding |
Light Sensors | 4 |
Application Fields | MMA 5>400 / TIG 2>300 / MIG-MAG 5>400 |
Standards | CE / EN 175B / EN 166 / EN 379 |
Description
TECHNICAL SPECIFICATION
Inner lens part number 046825
Outer lens part number 043893
• Panoramic visibility : 1 screen XL + 2 side screens fora 180° vision.
• 4 sensors for improved performance.
• TIG welding > 2A.
• Active filter : shades 4-8 / 8-12
• Range 4-8 : ideal for low amperage
• Choice of 7 tinted shades ( 4>12) suitable for all welding and cutting jobs.
• Technology TRUE COLOR (only on the main screen)
