Features
- Bare manganese-silicon alloyed solid wire for Gas Metal Arc Welding (GMAW) of unalloyed and fine-grained carbon-manganese steels
- Non-copper-coated formulation reduces fume emission, lowers spatter levels, and enhances corrosion resistance
- Advanced Surface Characteristics (ASC) Technology ensures smooth, trouble-free feeding at high wire speeds and long cable runs
- Esab Octagonal Marathon Pac® 5 kg spool delivers efficient handling, easy disposal, and minimal scrap for mechanized and robotic welding
- Compatible with pure CO₂ or argon/CO₂ shielding gases (C1, M20, M21 per EN ISO 14175)
- Minimum yield strength of 420 MPa with typical tensile strengths up to 586 MPa depending on shielding gas
- Excellent arc stability at high currents with reduced contact tip wear and superior start properties
- 0.8 mm diameter wire on a 5 kg spool (SKU 1A50084600) for precise, high-productivity welding
Specifications
| Last Modified | 28/06/2025, 08:27:13 |
| Weight | 5 kg |
| Data Sheet | https://www.elmdale.co.uk/files/ESAB_OK_Aristorod_1250_PDS.pdf |
| Diameter | 0.8 mm |
| Spool weight | 5 kg |
| Wire coating | Non-Copper coated |
| ISO classifications (Weld Metal) | EN ISO 14341-A: G 38 3 C1 3Si1; EN ISO 14341-A: G 42 4 M20 3Si1; EN ISO 14341-A: G 42 4 M21 3Si1; EN ISO 14341-A: G 3Si1 |
| AWS classification | SFA/AWS A5.18: ER70S-6 |
| CSA classification | CSA W48: B-G 49A 3 C1 S6 |
| JIS classification | JIS Z 3312: YGW 12 (C1) |
| Approvals | ABS 3Y SA; BV SA3YM; CE EN 13479; DB 42.039.29; DNV-GL III YMS; LR 3YS H15; PRS 3YS (C1); RS 3YMS; VdTÜV 10052; CWB B-G 49A 3 C1 S6; RINA 3Y S |
| Alloy type | Carbon-manganese steel (Mn/Si alloyed) |
| Shielding gases | C1 (100% CO₂), M20 (80% Ar/20% CO₂), M21 (75% Ar/25% CO₂) |
| Minimum yield strength | 420 MPa |
| Typical tensile properties (100% CO₂) | Yield 448 MPa; Tensile 538 MPa; Elongation 25 % |
| Typical tensile properties (75% Ar/25% CO₂) | Yield 455 MPa; Tensile 565 MPa; Elongation 28 % |
| Typical tensile properties (90% Ar/10% CO₂) | Yield 510 MPa; Tensile 586 MPa; Elongation 30 % |
| Typical Charpy V-Notch (As welded) | −20 °C: 90 J; −30 °C: 70 J; −40 °C: 60 J |
| Wire composition (%) | C 0.08; Mn 1.46; Si 0.85; S 0.012; P 0.013; Ni 0.04; Cr 0.03; Mo 0.01; Cu 0.07 |
| Deposition data (0.8 mm) | 60–200 A; 18–24 V; 3.2–10.0 m/min feed; 0.8–2.3 kg/h deposition |
Documentation
