Features
- Suitable for internal use; not recommended for hoisting operations.
- Maximum static load per beam 60 N and dynamic peak load 100 N.
- Operating temperature range from +5 °C to +80 °C.
- Galvanised frame for enhanced corrosion resistance.
- Made from round 25 x 1 mm longitudinal welded carbon steel tubes.
- Lightweight design, free-moveable in any direction by hand.
- Overall screen height 1972 mm and functional width 2002 mm.
- Curtain height 1700 mm with open seam at top and bottom.
- Curtain ISO EN 25980 approved for welding protection.
- No castors included; foot profiles 600 mm for stability.
- Delivered in loose parts with metric M8 fasteners for assembly.
- Zinc plated finish to protect against corrosion.
Specifications
Type of welding screen | Light weight screen |
Last Modified | 28/06/2025, 08:26:16 |
Weight | 8.5 kg |
Width | 200.2 cm |
Height | 197.2 cm |
Maximum static load beam | 60 N |
Maximum dynamic peak load beam | 100 N |
Range | Free moveable in any direction |
Overall size height | 1972 mm |
Functional width | 2002 mm |
Fasteners | Metric |
Castor | Not included |
Operation | By hand |
Finishing | Zinc plated |
Materials | Steel tube |
Application | Internal use |
Curtain height | 1700 mm |
Curtain approval | ISO EN 25980 |
Curtain thickness | 0.4 mm |
Operating temperature | +5 to +80 °C |
Foot profile length | 600 mm |
