Features
- Clamping force up to 22,000 N at tightening torque of 70 Nm.
- Long life due to heat-resistant pressure plate with sintered steel insert.
- Forged sliding arm made from tempered drop-forged steel for long service life.
- Heat treated, high carbon Acme threaded screw, tempered and quenched for greater load capacity and longer service life.
- Spatter resistant surface finish.
- High-strength electro-galvanized sliding pin T-handle with rounded ends for comfort, size engineered to load capacity.
- Tommy bar with rounded ends for comfort and simple transfer of force when clamping.
- 19 mm hexagonal bolt on the end of the spindle.
Specifications
| Last Modified | 28/06/2025, 08:25:37 |
| EAN Code | 4008158007625 |
| Weight | 6.67 kg |
| Clamping Force | Up to 22,000 N at tightening torque of 70 Nm |
| Pressure Plate | Heat-resistant with sintered steel insert |
| Sliding Arm Material | Tempered drop-forged steel |
| Screw Type | Heat treated, high carbon Acme threaded screw |
| Surface Finish | Spatter resistant |
| Sliding Pin | High-strength electro-galvanized sliding pin T-handle |
| Tommy Bar | Rounded ends for comfort and simple transfer of force |
| Hexagonal Bolt | 19 mm on the end of the spindle |
Description
BESSEY STB50M High-performance clamp, heavy duty STB 500/175, BE101923 - Clamping force up to 22,000 N at tightening torque of 70 Nm. Tommy bar with rounded ends for comfort and simple transfer of force when clamping. Forged sliding arm is made from tempered. Drop-forged steel for long service life. Heat treated, high carbon Acme threaded screw – tempered and quenched to give greater load capacity with longer service life. Spatter resistant. High-strength electro-galvanized sliding pin T-handle – rounded ends for comfort, size engineered to load capacity
