Features
- Clamping force up to 12,000 N at tightening torque of 40 Nm.
- 20% more clamping force per spindle rotation with optimized rail profile.
- Maximum safety due to better linear transfer of force of the sliding arm.
- Long life due to heat-resistant pressure plate with sintered steel insert, tiltable up to 35°.
- Maximum stability with optimized profile shape for greater clamping force build-up.
- Fixed clamp forged from a single piece with molded pressure plate, hardened, tempered, and galvanized for durability and torsion resistance.
Specifications
Last Modified | 28/06/2025, 08:26:04 |
EAN Code | 4008158007229 |
Weight | 2.58 kg |
Length | 25 cm |
Height | 14 cm |
Clamping Force | Up to 12,000 N |
Throat Depth | 140 mm |
Opening | 250 mm |
Rail Dimensions | 34 x 13 mm |
Pressure Plate Material | Heat-resistant with sintered steel insert |
Pressure Plate Tilt | Up to 35° |
Construction | Forged from a single piece, hardened, tempered, and galvanized |
